    340kg High Impact Hydraulic Concrete Breaker 175mm tool chisel For Hard Rock Stone Mining

    Ask Lasest Price
    Brand Name : Dopro
    Model Number : DPBB1650
    Certification : ISO CE
    Price : 800-8000
    Supply Ability : 8000 Pcs Per Month
    Delivery Time : 5-7 Working Day
    • Product Details
    • Company Profile

    340kg High Impact Hydraulic Concrete Breaker 175mm tool chisel For Hard Rock Stone Mining

    High Performance rock drill hydraulic rock breaker175mm tool chisel Hyundai R500 for gard rock stone mining heavy duty


    How does a hydraulic rock drill work?
    It works by using a piston and fiber head to rotate and create high-speed airflow for heat dissipation. Hydraulic rock drilling is a process that uses a hydraulic machine to drill into rock or soil. The machine uses a motor to rotate a drill bit and a hydraulic cylinder to control the movement of the drill bit


    It integrates powerful rock drilling equipment with an excavator, allowing for efficient drilling, blasting, and excavation in hard rock or mineral deposits.


    ARE YOU LOOKING FOR A RELIABLE FACTORY FOR HYDRAULIC BREAKER TOOL-CHISEL/MOIL/WEDGE WITH
    STABLE QUALITY & AFTER-SALES SERVICE GUARANTEES?

    DO YOU HAVE CLIENTS WHO WANT TO BUY THE DURABLE LONG LIFETIME & HIGH-END FINISH HYDRAULIC
    HAMMER TOOLS AS JAPAN OR KOREA'S?

    ARE YOU FINDING JAPAN/KOREA SUPPLIERS' OFFER SO HIGH AND THINK ABOUT
    A BETTER ECONOMIC ALTERNATIVE?

    HOW ABOUT A PERSON HELP YOU TO SOLVE ALL THE PROBLEMS AND LEAVE YOU
    TO SIT BACK AND RELAX?


    Choose us-Dopro


    DOPRO is a professional manufacturer committed to the design and production of Hydraulic Breaker and Attachments Whether your job is breaking down concrete surfaces, trenching, or preventing blockage in crushing systems, DOPRO is made to withstand continuous breaking in harsh environments. We DOPRO use only high quality low materials to produce superior product and all the manufacturing process such as heat treatment, forging, machining, grinding and ets, are strictly controlled by qualitied and experienced engineers in our factory with computerized and latest facilities. All parts are thoroughly inspected at every time that each process such as cutting, heat treatment, machining, grinding, cleaning, assembly, etc. is carried out, and all inspection data per each production lot are maintained and controlled so as to be utilized as data for better qualities and performance improvement. Major parts such as piston cylinder and etc are designed for outstanding durability through structure analyses, and mass production is started only when a proto type has been completely


    Advantage :

    1. Material: We use the special raw materials and plantary gear, which has high efficiency and long service life.

    2. Process: We have advanced production technology and quality testing.
    3. Delivery: We usually take about 7-15 days depending on the products you order after receive your payment.
    4. Price: High quality with competitive price. With us your money and your business is safe.
    5. After-sales service: Excellent technical support, complete service system. 12 months


    SPECIFICATION
    Model DPBB400DPBB450DPBB530DPBB680DPBB750DPBB1000
    Suitable
    Excavator
    Minton0.81.22.54611
    Maxton2.534.57916
    Suitableton1236714

    Tool
    (MoilType)
    WeightKg469202559
    Diametermm4045536875100
    Operating Weight
    (Tool+MC)
     Kg102126152295375861
     lb2983203976838381962
    Height mm113512131317162018992316

    Operating Pressure
    (Breaker)
     bar80~10080~10090~12095~130100~140150~170
     psi1,160~1,4501,160~1,4501,305~1,7401,377~1,8851,450~2,0302,175~2,465

    Setting Pressure
    (Machine)
     bar150150150170180200
     psi217521752175246526102900
    Impact Rate bpm800~1,400700~1,200600~1,100500~900400~800350~700

    BackHead Pressure
    (N2-Gas)
     bar/psi14/20314/20316/23216/23216/23216/232
    Required Oil Flow l/min15~3020~4025~5040~7050~9080~110

    SPECIFICATION
    Model DPBB1350DPBB1400DPBB1500DPBB1550DPBB1650DPBB1750
    Suitable
    Excavator
    Minton161825283040
    Maxton212630354055
    Suitableton202424344050

    Tool
    (Moil Type)
    WeightKg125129129193233311
    Diametermm135140150155165175

    Operating Weight
    (Tool+M/C)
     Kg150017662071263234003991
     lb3968445344535820705511089
    Height mm268228133063321533953736

    Operating Pressure
    (Breaker)
     bar160~180160~180160~180160~180160~190160~200
     psi2,320~2,6102,320~2,6102,320~2,6102,320~2,6102,276~2,7022,276~2,845

    Setting Pressure
    (Machine)
     bar210210210220240240
     psi304530453045319034803480
    Impact Rate bpm350~600350~500300~450300~450250~400200~350
    Back Head Pressure
    (N2-Gas)
     bar/psi16/23216/23216/23216/23217/24618/261
    Required Oil Fow l/min100~150120~180150~210180~240200~260210~290


    More model can fit
    KomatsuPC20 PC30 PC40 PC55 PC60 PC100 PC120 PC180 PC200 PC210 PC220 PC240 PC260 PC300 PC360 PC400 PC450 D20 D30 D31 D50 D60 D65 D61 D80
    D85
    HitachiEX30 EX30 EX55 EX60 EX100/120 EX150 EX200 EX210 EX220 EX300 EX350 EX400 EX450 ZX55 ZX70 ZX200 ZX240 ZX270 ZX330 ZX350 FH150 FH200
    FH300/330 UH07 UH13 UH063 UH081 KH70 KH100 KH125 KH150 KH180
    CATE70 E120 E240 E300B E305.5 E307 E311/312 E320 E322 E325 E330 E345 E450 CAT215 CAT225 CAT235 D3C D4D D4H D4E D5 D5H D5H D6D D6E D6H
    D7G
    KobelcoSK07C SK03N2 SK55 SK60 SK100 SK20 SK140 SK200 SK210 SK220 SK230 SK350 SK260 SK30 SK310 SK320 SK330 SK350 SK450 K907 PH335 PH440
    PH550 BM500 5045 7035 7045 PH7055 CKC2500
    MitsubishiMS110 MS180
    YuchaiYC35 YC60 YC65 YC85
    otherBS2F BS3F BD2G UB1 12HD CCH500 CCH1500 LB944 SP33
    SumitomoSH60 SH120 SH20 SH220 SH280 SH300 SH350 LS108 LS118 LS2800
    KatoHD250 HD307 HD450 HD700 HD770 HD800 HD820 HD1250
    HyundaiR55 R60 R80 R130 R200 R210 R215 R225 R230 R290 R320 R450
    Daewoo/DoosanDH55 DH60 DH150 DH220 DH280 DH300
    SamsungSE210 SE280 SE350
    VolvoEC55 EC140 EC210 EC240 EC290 EC360 EC460
